EXFO Reveal 5G troubleshooting
EXFO Reveal provides trace-level troubleshooting from Core-to-RAN-to-device-to-subscriber, with deep packet inspection, protocol decoding and CP-UP correlation. Programmable tracing policies can be applied to the cloud-native cProbe, triggered by end users, third-party apps, AI-powered analytics and automated diagnosis platforms.
Powerful analysis tools
Network performance and telemetry data can be displayed as raw packets, message and event grids, detailed protocol decoding trees, ladder diagrams, charts or as a hex dump, speeding analysis.
Granular performance insights
Drill down into 3GPP network function events, XDRs sourced from probes or traces, and raw traffic to successfully troubleshoot network impairments.
Unique capabilities
EXFO Reveal offers granular insights into network, service, device and subscriber performance
Core-to-RAN visibility
Dig deep into the user plane, control plane, and every network element—both 4G and 5G—regardless of vendor. Mix data from probes and network function events into a single view.
Single-pane perspective
Drill down into granular session records, traffic and session distributions, geo-analytics and more—all from an intuitive UI that maximizes efficiency and speeds up resolution.
Multiple trace levels
Choose live data for tasks such as 5G configuration and tuning, or historical data for rapid root-cause analysis.
User experience insights
Identify every network element and interface that affects a voice call, video chat, connected vehicle service or other critical application with per-user visibility in just 3 seconds.
Use cases
Powerful troubleshooting and analysis accelerate the resolution of network, service, device and subscriber issues
Missing or mixed 5G legs
EXFO Reveal makes it simple to identify and troubleshoot a variety of 5G situations, ranging from unprovisioned 5G users in the HSS, to missing 5G legs, to a 5G dual connectivity call. mixing a 5G leg and a 4G leg.
IMS Authentication
Using an EXFO Reveal ladder diagram and protocol decoding, it’s possible to identify a misconfiguration with the IMS authentication algorithm.
VoLTE registration
We were able to determine that the domain configured at the SIM is different from the domain configured at the I-CSCF.
Next steps
Discover the benefits of deep troubleshooting
