LTB-12 rackmount modular mainframe | Product

Características principales

Compact 4U solution with high port module density for in-rack and tabletop applications

Hot-swap capability for quick transitions between both rackmount and portable platforms

RAID1 mirroring for redundancy and data protection

Simple, easy-to-use industrial grade computer design with the Microsoft Windows operating system

Out-of-band management: optimal remote access for maintenance or initial setup using Intel® Active Management Technology (AMT)

Powerful and flexible enough to run automation software and scripts without an external personal computer

Maximum connectivity options with USB3, LAN, HDMI and VGA ports

Accessibility: remote access capability via VNC or Remote Desktop. Third-party tools can be easily installed for a versatile range of applications

Aplicaciones

Active and passive component testing

Transceiver manufacturing

WSS and ROADM calibration and tests

Sensing and spectroscopy

Spectral characterization

Description

The optical testing market is growing and evolving. Network equipment manufacturers and research laboratories need versatile solutions that address the numerous testing requirements of the market. With its small format, ultra-powerful processing and highly intuitive interface, the LTB-12 is optimized for lab users to carry out dedicated test applications simply and efficiently for a variety of technologies, including photonic integrated circuits (PICs), WSS, ROADM, passive optical components and more.

Windows advantage

Keep it simple and use the same applications you always have including Microsoft Office Suite (i.e., Word, Excel and PowerPoint) and other familiar programs.

Faster start times and multitasking deliver a superior user experience
Familiar desktop design makes the LTB-12 easy to use
Remote connection via Microsoft Remote Desktop

Supports optical test modules

The FTBx optical module family is EXFO’s next-generation test solution

Enjoy a full suite of advanced optical functionalities including power sensing, attenuation, switching, spectrum analysis, light source and OTDR/iOLM
Take control of each module with a user-friendly graphical user interface
Combine capabilities to build customized measurements

Automation for manufacturing

Thanks to a complete list of programming interfaces, the LTB-12 is ready to be automated using proven industry methods, including but not limited to: SCPI, IVI, RESTful Web services, TCP/IP, VISA, Ethernet, ActiveX, GPIB (optional) and RS-232 (optional).

Choose your preferred integrated development environment (IDE), install on LTB-12 hard drive, select a programming language among Python, LabVIEW, C#, TCL, MATLAB^®, C++, Visual Basic and start coding.

Fiber inspection and verification

Taking the time to properly inspect a fiber optic cable can prevent a slew of problems down the line—saving you time, money and headaches. Plug EXFO’s FIP-430B into a USB port on the LTB-12 and through EXFO’s ConnectorMax2 Analysis Software, quickly see if connectors pass or fail inspection.

The FIP-430B automates each operation in the connector endface inspection sequence, transforming this critical process into one quick and easy step
The ConnectorMax2 is an analysis software application that works with EXFO’s fiber inspection probes enabling technicians to:

View and automatically analyze connector images, eliminate guesswork and deliver quick pass/fail assessment of connector endfaces.
Generate reports and document jobs with EXFO's reporting tool
Save time and money in the lab

For complete automation in your manufacturing or deployment process, EXFO offers a RESTful Web services API and a comprehensive software development kit (SDK):

Use programming to select test configuration and start an inspection sequence
Retrieve measurement results and PASS/FAIL status
View live image of connector

Remote monitoring and control

Use remote access applications such as VNC, Remote Desktop or web browsers to monitor and troubleshoot test applications carried out on an LTB-12 platform located anywhere in the world.
